    48 Port LC OM4 Fiber Optic Rack Mount Patch Panels Type 1U Metalic Black Steel Material

    Ask Lasest Price
    Brand Name : KCO, Kocent Optec Limited
    Model Number : Slide Patch Panel
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : Western Union, T/T, L/C
    Supply Ability : 20,000 pcs/ month
    Delivery Time : 7~14 days after get payment
    • Product Details
    • Company Profile

    48 Port LC OM4 Fiber Optic Rack Mount Patch Panels Type 1U Metalic Black Steel Material


    48 Port LC OM4 Fiber Optic Rack Mount Patch Panels Type 1U Metalic Black Steel Material

    Application:
     Sliding rack mount patch panel integrates the 3 functions of fiber fusion, storage and distribution.
     It's used widely in local end main cable net of fiber optic communication area.
     And suitable for the FTTB, FTTH system.

    Feature:
     High quality cold rolled sheet forming, electrostatic powder spraying technology, smooth surface, not east to rust.
     High strength sheet metal, long-term using is not easy to deformation.
     The edges of metal parts are designed with rounded corners to avoid damage to cables.
     The bottom plate is designed with sliding design, for the patch panel already installed on the cabinet, the wiring can be adjusted without removing the patch panel.

    Product data:
     Standard: 19" rack mount dimention.
     Cable entrance: 4 ports, ⌀ 25mm.
     With cable lead-in, fixation and protection devices.
     There is enough room for fiber storage, ensure the bending radius is 15 times diameter of the cable.
     Providing relevant accessories.

    Environment:
     The operating and storage temperature: - 45 ~ + 80 ℃.
     Tolerable humidity: <95%.
     The voltage resistance between the cable grounding device in the shell and the shell is >3000V(DV), which is tested in 1 minute without breakdown and no flashover.


    Parameters:

    Type19' Slide type fiber optic rack mountable patch panel
    P/NKCO-SPN18-A2
    Size485x300x1U/2U/3U/4U
    ColorWhite
    CapacityMax. 48 cores
    Insert loss≤ 0.2dB
    Return loss50dB (UPC), 60dB (APC)
    Durability1000 Mating
    Wavelength850nm,1310nm,1550nm
    Operating temperature-25°C~+40°C
    Storage temperature-25°C~+55°C
    Relative humidity≤85%(+30°C)
    Air pressure70Kpa~106Kpa
    ConnectorSC, FC, LC, ST, etc
    Cable0.9mm~22.0mm


    OEM/ODM Service:
    If you want to display your own brand LOGO on the goods such as cable, package bag, label or any where. It is no any problem. Our OEM and ODM service is always ready to do it.


    Packing:
    According to Stardard Export Packing.
    Carton box, wooden box, wooden pallet.

    Shipping:
    - International express such as UPS, TNT, DHL, etc
    - Internatioal air: CA, AA, EA, etc
    - By sea
