4port Wallmount Fiber Optical Termination Box 4Core SC/APC
Auto-shutter Adapter Pigtail
Description:
- FTTH KCO-FTB04B Model of Fiber Optic Terminal Box is a newly developed by our
company for application of FTTH.
- The box is light and compact, especially suitable for protective
connection of fiber cables and pigtails in FTTH.
- KCO-FTB04B adopts a compact plug-in design, combines a Integration,
Multi-function, Modern design concept.
- It is of a graceful appearance and applicable for FTTX network,
and easy use in different installation environments.
- The clasp design of the cover has greatly reduced the
installation strength.
- The box fit for FC, SC, ST, LC (duplex) adaptor, with good
bending protection.
- It is the termination for optical fiber user, specially designed to
construct FTTH.
- It can be installed at the corridors and multi-media cases for
optical fiber users.
- The methods of coldly-connected or hot-melted can be used to
connect the optical ends, and transmit the light by the adapterd or
end of fiber to the ONU of terminal user.
- The Products are in fine property, and universal for user. It is
widely applied in FTTX, LAN, Cable TV, and other telecom systems.
Quick Information:
| Part number | KCO-FTB04B |
| Size | 100x85x30mm |
| Capacity | 4 cores (for SC), 8 cores (for LC) |
| Material | Plastic ABS |
| Cable | indoor cable or FTTH cable |
| Cable diameter | Max. 10mm |
| Adapter | SC, LC, FC, ST, E2000, etc |
| Color | White |
Product picutures:
Application
- Widely used in FTTH access network
- Telecommunication networks
- CATV networks
- Data communication networks
- Local area Networks
Features
- Industry standard user interface, be made of high impact plastic
- Anti-UV, ultra violet resistant and rainfall resistant
- Can accommodate 4 SC/SX adapter or 4LC/DX adapter
- Up to 4 FTTH drops
- Wall mountable
- 4 cable port
Operating Conditions:
- Temperature -45~+85
- Relative humidity ≤85%(+30 C)
- Atmospheric pressure 70KPa~106KPa
Qualification:
- Nominal work wave-length: 850nm,1310nm,1550nm
- Connectors loss ≤0.2dB
- Insert loss ≤0.2dB
- Return loss >=50dB(UPC),>=60dB(APC)
- Insulation resistance (between frame and protection
- Grounding) >1000MΩ/500V(DC)
Parameters:
| Type | Indoor terminal box |
| P/N | KCO-FTB04A |
| Size | 150x117x30mm |
| Color | White |
| Capacity | Max. 8 cores |
| Insert loss | ≤ 0.2dB |
| Return loss | 50dB (UPC) 60dB (APC) |
| Durability | 1000 Mating |
| Wavelength | 850nm 1310nm 1550nm |
| Operating temperature | -25°C~+40°C |
| Storage temperature | -25°C~+55°C |
| Relative humidity | ≤85%(+30°C) |
| Air pressure | 70Kpa~106Kpa |
| Connector | SC, FC, LC, ST, E2000, etc |
| Cable | 0.9mm~10.0mm |
OEM/ODM Service:
If you want to display your own brand LOGO on the goods such as
cable, package bag, label or any where. It is no any problem. Our
OEM and ODM service is always ready to do it.
Packing:
According to Stardard Export Packing.
Carton box, wooden box, wooden pallet.
Shipping:
- International express such as UPS, TNT, DHL, etc
- Internatioal air: CA, AA, EA, etc
- By sea
