    Waterproof Fiber Optic Terminal Box , Outdoor FTTH Fibre Wall Box

    Ask Lasest Price
    Brand Name : KCO, Kocent Optec Limited
    Model Number : KCO-FTB-08W
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : Western Union, T/T, L/C
    Supply Ability : 20,000 pcs/ month
    Delivery Time : 7~14 days after get payment
    • Product Details
    • Company Profile

    Waterproof Fiber Optic Terminal Box , Outdoor FTTH Fibre Wall Box


    KCO-FTB-08W Indoor Fiber Optical Termination Box Wall-mount Socket FTTH ABS White


    Descriptions:
    - KCO-FTB-08W fiber optic termination box is design for indoor application with 8 port adapter, can install SC simplex, FC simplex, ST simplex, E2000 simplex or LC suplex adapter.

    - KCO-FTB-08W fiber optic termination box can install indoor wall mount or be a desktop socket box.

    - Fiber optic terminal box KCO-FTB-08W is a box for fiber terminal distribution in optical fiber transmission and communication network. It can be 08 fibers splicing, protection and distribution.

    - It is used as a termination point for the feeder cable to connect with drop cable in FTTx network system.

    - It integrates fiber splicing, splitting, distribution, storage and cable connection in one solid protection box.

    - The optical distribution box is a solution that facilitates the installation of optical termination in branch networks for FTTH environments.

    Features:

    - Material: ABS or ABS+PC plastic.

    - Long life time

    - Can load 08pcs LC, FC, ST, SC, E2000 … adapters.

    - Wall mounting application.

    - The cover with 2 reinforcing closing pieces, easy to open and close.

    - 08 ports of adapter holder.


    Products photos:




    Specifications:

    ModelKCO-FTB-08W
    MaterialPC+ABS or ABS
    Dimension210*110*30mm
    Cable Entry2 cable entrance: 10-16.5mm
    Drop cable port08 ports
    Applicable cable diameter2*3mm FTTH drop cable, 2*5mm figure 8 FTTH drop cable
    Max. Capacity8 Fibers, 1 tray x 8F
    AdapterMax. 8pcs SC simplex (LC, FC, MT optional)
    Sealing structureMechanical sealing with PE waterproof sealing ring
    PLC SplitterMax. micro plug-in 1x12 Splitter
    ColorGray White or Black
    IP GradeIP55
    Operating Temperature-40°C~+80°C
    Relative Humidity<95%(+40°C)
    Insulated Resistance>2x10MΩ/500V(DC)
    Installation Method
    (in overstriking)
    Floor Standing / Wall Mounted / Pole Mounted /
    Corridor Mounted / Mounted in Cabinet


    Dimension:

    Model
    Capacity
    Dimension (LxWxH)
    Weight
    KCO-FTB-08W
    1*8 PLC splitter, 08 SC adaptors
    280*110*30MM
    0.3kg
    Packing1pc/box3000*120*40MM

    OEM/ODM Service:
    If you want to display your own brand LOGO on the goods such as cable, package bag, label or any where. It is no any problem. Our OEM and ODM service is always ready to do it.

    Packing:
    According to Stardard Export Packing.
    Carton box, wooden box, wooden pallet.

    FTTH 24 Port Fiber Optic Terminal Box KCO-FDB-24G Outdoor Water Proof ABS PC Material


    Shipping:
    - International express such as UPS, TNT, DHL, etc
    - Internatioal air: CA, AA, EA, etc
    - By sea
