Strength Member Loose Tube GYXTW Outdoor Fiber Optic Cable PE
Sheath 4~12core
Description:
- GYXTW is an outdoor use optical fiber cable suitable for duct and
aerial applications. We supply GYXTW fiber optic cable from 2 fiber
cores to 12 fiber cores. Both single mode type and multimode types
are available.
- The fibers, 250μm, are positioned in a loose tube made of a high
modulus plastic.
- The tubes are filled with a water-resistant filling compound.
- The tube is wrapped with a layer of corrugated steel tape
longitudinally.
- Between the corrugated steel tape and the loose tube
water-blocking material is applied to keep the cable compact and
watertight.
- Two parallel steel wires are placed at the two sides of the steel
tape.
- The cable is completed with PE sheath.
Parameter:
| Model | Fiber Count | Tube | Fillers | Cable Diameter
(OD) | Cable Weight
(kg/km) | Tensile Strength
Long/Short Term
(N) | Crush Resistance
Long/Short Term
N/100m | Bending Radius
Static/Dynamic
(mm) |
| GYXTW | 2~12 | 1 | 12 | 6.5 | 70 | 600/3000 | 1000/3000 | 10D/20D |
| GYXTW | 2~12 | 1 | 12 | 7 | 85 | 1000/3000 | 1000/3000 | 10D/20D |
| GYXTW | 2~12 | 1 | 12 | 8 | 100 | 1000/3000 | 1000/3000 | 10D/20D |
| | G.652 | G.655 | 50/125μm | 62.5/125μm |
| Attenuation | @850nm | | | ≤3.0 dB/km | ≤3.0 dB/km |
| (+20ºC) | @1300nm | | | ≤1.0 dB/km | ≤1.0 dB/km |
| @1310nm | ≤0.36 dB/km | ≤0.40 dB/km | | |
| @1550nm | ≤0.22 dB/km | ≤0.23dB/km | | |
| Bandwidth (Class A) | @850nm | | | ≥500 MHz·km | ≥200 MHz·km |
| @1300nm | | | ≥1000 MHz·km | ≥600 MHz·km |
| Numerical Aperture | | | | 0.200±0.015NA | 0.275±0.015NA |
| Cable Cut-off Wavelength λcc | | ≤1260nm | ≤1480nm | | |
Features:
- The two parallel FRP strength members provides enough tensile
strength.
- Special gel in the tube offers critical protection for the
fibers.
- Small diameter and light weight.
- PE jacket itself prevents UV, and UV material can be added to
perform much better.
- It's available under high and low temperatures anti-aging.
Application:
- Laying modes: Aerial & Conduit
- Rural communication, local trunk line, CATV & computer networks
system
Construction:
Q: What is your best price?
A: Based on the quantity of our products and the quantity of your
order, we would quote the best matcing price all the time.
Q: Can you provide OEM and ODM serveice?
A: KCO with more than 10 years of experience in OEM service, we get
many OEM order about fiber optic products. If you have request to
make a your own design with your own LOGO of fiber optic product,
please contact with our sales team to get best support.
Q: What is your MOQ?
A: Sample not quantity request, bulk order: at least 100pcs/ model.
Q: What is the lead time of my order?
A: Sample order: 3-5days, mass production order: 1-2weeks.
Q: Can I get a free sample?
A: New customer is not acceptable.
Q: How about the warranty?
A: 1 year for most products.
Q: How do you ship the goods to us?
A: - Sample / Small Order: DHL / TNT / UPS / Fedex / EMS / Aramex /
SF Express, ...
- Mass Production Order: by air / by sea
- Standard Export Port: Ningbo / Shenzhen
Q: Can you list some of your main customers?
A: Dosmetical customers include: Huawei, ZTE, Fiberhome, China
Telecom, China Mobile, ... Abroad customers include: TE, Commscope,
Cisco, Cerizon, Smart, ...
Q: Why choose KCO to cooperate?
A: - Reliable and exprerienced communication equipment manufacturer
for more than 10 years.
- First-class production line and strict quality management system.
- Professional procedure system and bulk production capacity to
guarantee fast delivery time.
- Most competitive price to meet your budget.
- Professional RD team to design and innovate new products ased on
our rich experience.
- Fast and Effective after sales service.
