MPO APC to 12 LC UPC Patch Cord Single Mode OS2 9/125 G652D 2.0mm
PVC 1m 3m 5m 10m
Descriptions:
- Connector side A:
MPO 12 cores
Polishing type: APC
- Connector side B:
LC/UPC 12 cores or 6*DLC/UPC
Other connector type: customized.
- Cable type:
Single mode G657A1
Other type: customized
- Low insertion loss and high return loss
- Fanout diameter: 0.9mm, 2.0mm, and 3.0mm
- Fanout Length: 0.3m, 0.5m or customized
- Excellent changeability and repeatability
- Tensile strength: 10N
- Operating temperature range: -40°C to 80°C
- Storage temperature range: -40°C to 80°C
- Color of fiber optic cable:
Singlemode: Yellow
Multimode OM1, OM2: Orange
Multimode OM3, Om4: Aqua
Multimode OM4: Pink
Multimode OM5: Green
Other color: customized
- Cable outsheath material: PVC, LSZH, OFNR, PE, TPU, etc
- Complies with IEC, Telcordia GR-326-CORE standard
Features:
- High reflection loss with APC
- Fiber in single connector: 4, 8, 12, 24 cores
- Single mode and multi mode (flat) APC (catercorner 8 degree
angled) are available
- High fiber density (maximum 24 fibers for Multimode)
- Insert/Pull latching connector
- Comply with Telcordia GR-1435-CORE specification and Rosh
standard
Applications:
- FTTH, CATV, LAN, MAN, WAN, Test & Measurement
- Video transmission, Data transmission
- Active Device Termination
- Premise Installations
- Telecommunication and Data processing Networks
- Industrial, medical & military
- Systems Integration for Long Haul, Metro and Access Network
Specifications:
| Type | Single Mode | Single Mode | Multi Mode |
| (APC Polish) | (UPC Polish) | (PC Polish) |
| Fiber Count | 8,12,24 etc. | 8,12,24 etc. | 8,12,24 etc. |
| Fiber Type | G652D,G657A1 etc. | G652D,G657A1 etc. | OM1,OM2,OM3 etc. |
| Max. Insertion Loss | Elite | Standard | Elite | Standard | Elite | Standard |
| Low Loss | | Low Loss | | Low Loss | |
| ≤0.35 dB | ≤0.75dB | ≤0.35 dB | ≤0.75dB | ≤0.35 dB | ≤0.60dB |
| Return Loss | ≥60 dB | ≥60 dB | NA |
| Durability | ≥500 times | ≥500 times | ≥500 times |
| Operating Temperature | -40℃~+80℃ | -40℃~+80℃ | -40℃~+80℃ |
| Test Wavelength | 1310nm | 1310nm | 1310nm |
| Insert-pull test | 1000 times＜0.5 dB |
| Interchange | ＜0.5 dB |
| Anti-tensile force | 15kgf |
Product Construction:
A: MPO connectot
L: Total length
L1: Fanout length
B: Connector ( FC, LC, ST, SC, ...)
Product Photo:
Ordering Informations:
MPO/PC–MPO/PC-SM-12CORE–2M-LSZH
① ② ③ ④ ⑤ ⑥
Notices:
①Connector type: FC, SC, LC, ST, MTRJ, MU, E2000, MPO, DIN, D4, SMA
②Ferrule End-face: PC, UPC, APC
③Core Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or
62.5/125um)
④Fiber Quantity: 4 core, 8 core, 12 core, 24 core
⑤Cable Length: 1, 2, 3 meter or customized
⑥ Cable type: PVC, LSZH, OM3, OFNR, OFNP, Plenum
